Technical features
- Basic data
- Series: 92
- Operating principle: Diffuse reflection principle with background suppression
- Special design
- Special design: Ex-protected
- Optical data
- Operating range, white 90%: 0.03 ... 0.3 m
- Operating range, gray 18%: 0.04 ... 0.25 m
- Operating range, black 6%: 0.04 ... 0.22 m
- Operating range limit: 0.03 ... 0.3 m
- Light source: LED, Red
- Electrical data
- Performance data
- Supply voltage UB: 5.5 ... 13 V, DC
-
- Timing
- Switching frequency: 60 Hz
- Interface
- Type: NAMUR
- Connection
- Connection 1
- Type of connection: Connector
- Thread size: M12
- Material: Metal
- No. of pins: 4 -pin
-
- Mechanical data
- Dimension (W x H x L): 20 mm x 80 mm x 42.2 mm
- Housing material: Metal, Diecast zinc
- Lens cover material: Glass
- Net weight: 140 g
- Environmental data
- Ambient temperature, operation: -20 ... 50 °C
- Ex specification
- Ex device category: 2
- Ex-Spezifikation
- Ex-Zone: 1, 21
- Certifications
- Degree of protection: IP 67
- Protection class: II
- Certifications: Ex
- Standards applied: IEC 60947-5-2
- Classification
- Customs tariff number: 85365019
- eCl@ss 8.0: 27270904
- eCl@ss 9.0: 27270904
- ETIM 5.0: EC002719
- ETIM 6.0: EC002719
-
-
