Technical features
- Basic data
- Series: EMS
- Type of signaling: Acoustic
- Electrical data
- Performance data
- Supply voltage UB: 230 V, AC/DC, 10 %
- Current consumption, max.: 22 mA
-
- Connection
- Connection 1
- Type of connection: Terminal
-
- Mechanical data
- Design: Cubic
- Dimension (W x H x L): 94 mm x 94 mm x 92.5 mm
- Housing material: Plastic, PC
- Net weight: 300 g
- Housing color: Red
- Type of fastening, at system: Screw type
- Operation and display
- Operational controls: DIP switch, 270° potentiometer
- Function of the operational control: Selection of tone type, Volume control
- Environmental data
- Ambient temperature, operation: -30 ... 60 °C
- Certifications
- Degree of protection: IP 66
- Certifications: c UL US
- Acoustic data
- Tone type: Multi-tone
- Audio frequency: 150-2900 Hz
- Sound pressure: 108 dB
- Number of tones: 32 Piece(s)
- Classification
- Customs tariff number: 85318070
- eCl@ss 8.0: 27371214
- eCl@ss 9.0: 27371214
- ETIM 5.0: EC001026
- ETIM 6.0: EC001026
-
-
Accessories
-
Downloads
- Technical documentation : (16)
Type Designation Language File size Format Operating instructions Language-independent 635,7 KB pdf Data sheet Chinese (simplified) 573,7 KB pdf Data sheet Danish 568,4 KB pdf Data sheet German 575,9 KB pdf Data sheet English 577,2 KB pdf Data sheet French 587,8 KB pdf Data sheet Italian 569,5 KB pdf Data sheet Japanese 578,6 KB pdf Data sheet Korean 556,3 KB pdf Data sheet Dutch 577,5 KB pdf Data sheet Portuguese 576,6 KB pdf Data sheet Spanish 575 KB pdf Data sheet Turkish 570,4 KB pdf Mounting instructions Language-independent 1,6 MB pdf Product brochure German 1,3 MB pdf Product brochure English 1,3 MB pdf - Certificates : (3)
Type Designation Language File size Format Declaration of Conformity German 70 KB pdf Declaration of Conformity English 70 KB pdf Declaration of Conformity French 70 KB pdf
-
Part data of:2019-09-16 18:32:00
