Technical features
- Basic data
- Type of signaling: Acoustic
- Electrical data
- Performance data
- Supply voltage UB: 12 ... 24 V, AC/DC
- Current consumption, max.: 46 mA
-
- Connection
- Connection 1
- Type of connection: Terminal
-
- Mechanical data
- Design: Cylindrical
- Dimension (? x L): 30 mm x 59 mm
- Length in installed state: 12 mm
- Housing material: Plastic, PC
- Net weight: 30 g
- Housing color: Black
- Type of fastening, at system: In bore holes with ? 22.5 mm
- Environmental data
- Ambient temperature, operation: -20 ... 60 °C
- Certifications
- Degree of protection: IP 65
- Certifications: c UL US
- Acoustic data
- Tone type: Continuous or pulse tone
- Audio frequency: Approx. 3500 Hz
- Sound pressure: 65 dB
- Number of tones: 2 Piece(s)
- Classification
- Customs tariff number: 85318070
- eCl@ss 8.0: 27371214
- eCl@ss 9.0: 27371214
- ETIM 5.0: EC001026
- ETIM 6.0: EC001026
-
-
